Model | TIG-250C Argon arc welding/cold welding/DC welding machine | |
Input Voltage(V) | 1*220V-240V+1*110-120V | |
Frequency (Hz) | 50HZ/60HZ | |
Power Capacity (KVA) | 7.1 | |
Max Input Current (A) | 38 | |
No-load Voltage(V) | 62V | |
Rated working cycle（%） | 60 | |
TIG/MMA Current range(A) | 10~220/10~220 / 20~180 | |
MMA Range of thrust current（%） | 0-100 | |
Input Voltage(V) | 0-100 | |
TIG/DC | Welding current A | 10-250 |
Fall timeS | 0-15 | |
Aftergas time | 1-15 | |
TIG-COLD | ||
Welding current A | 10-220 | |
Fall timeS | 1-999 | |
Aftergas time | 0-10 | |
Welding current A | 0-15 | |
MMA | Electrode diameter （mm） | 1.6, 2.0, 2.5, 3.2, 4.0 |
Offset current (A) | ±5A | |
TIG Tungsten diameter （mm） | 1.0, 1.6, 2.0, 2.4, 3.2 | |
Efficiency（%） | 85 | |
Power factor | 0.93 | |
Protection level (S) | IP23 | |
Insulation level | F | |
Size（mm） | 380*160*240 | |
Weight（KG） | 6.9 | |
1: Minimum order quantity: 100 units 2: Price $115
TIG-250c cold welding machine is an IGBT inverter welding machine. This welding machine is a type of inverter arc welding power source, specifically designed for TIG DC welding using high-frequency or LIFT impact. The minimum welding time is 1 millisecond, and the maximum interval time is 10 seconds. Different welding requirements can be achieved by adjusting the welding time separately. The instantaneous impact current can reach 220 amperes, and it can weld a minimum of 0.1mm plate. The manual arc can weld (acidic, alkaline) welding rods. This inverter welding machine has the characteristics of high speed and precise adjustment, which can achieve excellent welding quality.
